Fingerprint Reader Tripod Turnstile Gate 110V 220V 30 Person / Minute



Fingerprint Reader Tripod Turnstile Gate 110V 220V 30 Person / Minute



Fingerprint Reader Tripod Turnstile Specifications:





Description:

(1) Running stably without noise and mechanical impact.

(2) The passing person number of the persons can be set.

(3) Bidirection or one direction permitted, one forbidden, or one direction charged,
one for free, and all the working molds set by the buttons in the main control board.

(4) Direction-guide lights in the turnstile to tell you whether the direction to go or not.

(5) Standard Interface. work with ID / IC. UHF. Fingerprint Readers

(6) Beam can be lifted and fall when power is cut-off.

(7) Self-check and alarm for convenient to operate.



Applications:
● Tripod Turnstile is an electro mechanical turnstiles. Its unique mechanical drive design allow the arm to

be pushed effortlessly and auto-rotate back without any expensive electric motor

●Tripod Turnstile can effectively control high volume human traffic ( up to 25 person per minutes ) while

still maintaining a welcoming atmosphere. They can easily be integrated with any electronic system for

ticketing, access control or time attendance.

●Tripod Turnstile is suitable for both indoor and outdoor(Shed). They are optimized economical solution

for railway, bus station, factory, colleges, commercial building, library, stadium, game park, hotel, super

market, bank and etc.


Turnstile accessories:
● Turnstile Mechanism (semi-auto)
● Turnstile housing (304# Stainless steel at 1.5MM)
● Turnstile Control Board
● Turnstile Supply
● Turnstile Traffic Indicator(double direction)
● Turnstile Passage Status Lights

Communication with customers:
1 - Does the turnstile come with a RS485 PC software?
The turnstile itself doesn’t come with a RS485 PC software,you need purchase the RS485 door access

control and card reader.But we suggest you purchase TCP/IP door access control and card

reader.Because it doesn’t need converter,and use internet cable it can directly communicate with a

computer.Compare with RS485 door access control,It is more convenient and transfer speed much faster.

2- Can I communicate the turnstile direct with a PC?
No,you can’t communicate the turnstile directly with a pc,because the main board just out put low level

signal,but pc can not receive low level signal,so the turnstile must connect a door access control then can

connect with a pc.

3 - They come with the complete command manual (if we want to develop our own software)?

For normal passage control,we have compete command manual for you.,Many clients from different

countries use our software,don’t need second develop.If your company has the ability to develop your

own software, we can provide SDK to you.
4- can I use just one access control control 2 pcs turnstile?
You can use one one access control for double doors to control 2pcs turnstile,but the 2 turnstiles must be

very close,because if the distant is far,first,it will not convenient to set up the cable,second the single will

be less then can influence the whole facility.So,for 2 doors,we suggest you use 2 access control.



Applications:
The tripod turnstiles can be used in places such as restaurants, hotels, office buildings, museums, gyms,

clubs, metros, bus stations, high class communities, intelligent buildings, hotels, subway stations and

other high level venues, ect.



Fingerprint Reader Tripod Turnstile Picture:


tripod access system

tripod barrier gate

Fingerprint Reader Tripod Turnstile Gate 110V 220V 30 Person / Minute Images
