RFID automatic roller revolving speed gate turnstile In outdoor public service

Name: RFID automatic roller revolving speed gate turnstile In outdoor public service
Brand: Goldantell
Price: 1 USD

Brand Name : Goldantell

Model Number : GAT-340

Certification : CE/ROHS/FCC/IS9001

Place of Origin : Guangdong,China

MOQ : 1pc

Price : negotiation

Payment Terms : T/T ,western Union,LC,Paypal, L/C

Supply Ability : 2,000pcs per month

Delivery Time : 7 working days after received your payment

Packaging Details : Packed in carton firstly,and then reinforced with export wooden case for outer packing

Working voltage : AC220±10%V 50±10%HZ

Communication port : RS485 ,TCP/IP

Passage width : ≤600 mm

Compatible : RFID Reader&Fingerprint Reader ,Coin access,QR code reader,Bar code System,ESD Tester Access Control, remote button

Materal : 304 stainless steel/316 stainless steel

Transit speed : 30-40 people/minute

Service life : 3000,000 times

Arm width : 550 mm

Time of opening : 0.2 second

Pass speed : 30 persons/min

Communication interface : standard RS485 interface, distance ≤1200m

Contact Now

RFID automatic roller revolving speed gate turnstile In outdoor public service

Specifications:

Item

GAT-340

Housing material:

304 stainless steel/316 stainless steel

Working voltage:

AC220±10%V 50±10%HZ

Arm length:

550mm

Time of opening:

0.2 second

Passage width:

≤600mm

Direction

single or bi-directional (optional)

LED light

direction arrow

Emergence

When power off, arm open automatically

Drive motor

DC 24 V brush motor

Support force of arm:

60kg

Input interface:

+12V level signal or pulse width>100 ms
12V pulse, drive current>10 mA

Features of tripod turnstile:

1. working method can be set by the buttons on the main panel
2. This model is double wing flap gate, low noise, smaller casing, save space
3. Anti-pinch by mechanism and sensor If there is block during return of gate, motor stops working automatically. Reset again after a default delay, the force 2Kg.
4. Anti-illegal in, anti-intrusion, auto close for reverse direction.
5. Anti-collision, gate closes when no valid signal is given.
6. Gates can be synchronous
7. uto-reset. If not go through in a preset time, pass right would be cancelled automatically. (1-60s adjustable), default time is 10s.
8. Reset function by photocells,Anti-pinch function by photocells, ( 3 or 5 pairs sensors)
9. Compatible with Access control system, consumption system, ESD system, E-ticket system and so on.
10. One way or two way control
11. Unit can be controlled and administered by remote control

Application place :

· Supermarket

· Subway Station, Bus Station

· ,Airports

· Tourism

· Exhibition

· Theater

· Swimming Hall

· Fitness Gym

· Residence Area

· Enterprise’s Entrance and Exit Attendance

· Toll Management

Advantages

Matt finished housing surface, dustproof and rainproof design for outdoor use.
Highly integrated solenoid mechanism, 100% heavy duty operation.
Drop arm when power off, for emergency use.
Convenient installation and maintenance.
Malfunction self-detection. Which is easy for operation and maintenance.
Audible and visual alarm in case of unauthorized access
Friendly and professional customer service people help you in 16 hours
we can provide not only product, but also system software management.
