Full automatic rotating gate tripodHalf Height Turnstiles in universal remote control

Brand Name : Goldantell

Model Number : GAT-303

Certification : CE/ROHS/FCC/IS9001

Place of Origin : Guangdong,China

MOQ : 1pc

Price : negotiation

Payment Terms : T/T ,western Union,LC,Paypal, L/C

Supply Ability : 2,000pcs per month

Delivery Time : 7 working days after received your payment

Packaging Details : Packed in carton firstly,and then reinforced with export wooden case for outer packing

Motor : DC24V solenoid valve

Housing material : domestic standard 304# stainless steel

Compatible : RFID Reader&Fingerprint Reader ,Coin acess,QR code reader,Bar code System,ESD Tester Access Control, remote button

Arm width : Arm width: 500 mm

Time of opening/closing : 0.2 second

Passage width : 600mm

Support force of arm : 60kg

Communication interface : Communication interface: standard RS485 interface, distance ≤1200m

Pass speed : Pass speed: 30 persons/min

Contact Now

Full automatic rotating gate tripod turnstile in universal remote control

 Specifications:


Item

 GAT-303


Passage width


600mm

Pass speed:


 40 persons/min (open), 25-30 persons/min (closed)

Reset time after break down:


 10 seconds

Direction:


single or bi-directional (optional)

Communication interface


standard RS485 interface, distance ≤1200m

Input interface:


RFID Reader&Fingerprint Reader ,Coin acess,QR code reader,
Bar code System,ESD Tester Access Control, remote button


 Support

operating video& Instruction will be sent to clients to help them better use the machines


Emergence:

 When power off, arm open automatically


Trade terms


EX-W,FOB,CIF,DDU(select area)


 Function:



  • The gate is Bidirectional, according the infrared sensing to enter and exit the passageways.
  • Turnstile can setting the working condition by press the button of main control board.
  • Anti-pinch function: turnstile have Mechanical/ infrared induction Anti-pinch functions( when it is meet the hinder during the reset time, the electrical machine closed work automatically in specified time, the turnstile will default the delayed and reset again till reset succeed)
  • The turnstile will lock when somebody enter the gate illegal, Tailgating or break into negative direction gate.
  •  Before received the open signal, the turnstile will lock automatically
  •  The arm have the collision avoidance function: when the turnstile arm closed, if it is under the collision, the arm will open to protect the Transmission of inner machine.
  •  Automatic Reset Functions: after you swap the card, during the specific time (the system is 10s), if you didn’t pass the turnstile, the system will cancel your authority automatically to pass the gate, (reset time is 1~60s you can adjust it what time is suit for you). totally meet the fire protection needs
  • The turnstile can work with door access control system/ consumption system /biometric recognition system/ ESD system and so on
  • The turnstile is bidirectional (pedestrian can enter and exit from one pair of turnstiles)
  • Can manager and long-range control the turnstile directly by managing the computer.


 Control system:



access control system


access control system: fingerprint/ face recognition/
card reader/ QR code/ barcode ticket system.



charge management system


counter, coin- operation.


support special function


ESD tester system and function



Application:


  • Supermarket
  • Subway Station, Bus Station
  • ,Airports, Hoverport
  • Tourism
  • Exhibition,Hotel
  • Bank
  • ,Library,Theater
  • Swimming Hall,Fitness Gym
  • Residence Area
  • Enterprise’s Entrance and Exit Attendance


Appearance, Dimension, Material & Surface Finish:


  • Appearance: customized according to customer’s requirement.
  • stainless steel thickness of the cabinet: customized within 1.2~2.0mm.
  • Material of the cabinet: 304 / 316 grade stainless steel.
  • Surface finish of the cabinet: satin finish / polishing / anti-fingerprint/frosted finish / electroplating / baking

Full automatic rotating gate tripodHalf Height Turnstiles in universal remote control


Contact Way:

For convenient talk ,you can reach me by below :

Contact Person:Cherry Mao
Skype:goldantell03
Whatsapp:86+15815817112
E-mail: sales03@cctvgat.com
